H - S COMBINATION WALL SERIES

ESC's combination wall series are ideal when the standard series of sheet piles do not have the strength to resist the required design loads. The King H Piles withstand most of the bending loads (may include vertical loads), with the intermediate infill sheet piles to transfer the soil and water pressures to the King H Piles. The infill sheet piles can be shorter - between 60-100% of the King H Pile length.

H-Pile Sheet Pile combination wall

ESC-S INFILL SHEET PILES

Infill sheet piles

*excludes internal section of interlock

ESC S Infill Sheet Piles

ESC-H PILES PROPERTIES WITH PIPE-BAR INTERLOCK

Double H Pile

Double H Pile H-2 Series

H Pile

Single H Pile H-1 Series

*excludes internal section of interlock

Single H Pile Series
Combined Wall Properties

Combined Wall Properties ESC H-S Combi Wall

H Pile Sheet Pile Combined Wall
